• System Name – Displays the administratively assigned device name.
• System Description – Describes the device. For example, system hardware type and
version, operating system and network software.
• System Capabilities – Describes the primary device function. For example: Bridge,
Router.
Port Information
• Interface – Displays the port number.
• Port ID SubType – Displays the port ID type. For example, MAC address.
• Port ID – Displays the port identification of the port transmitting the LLDP frame.
• Port Description – Displays information about the port, including manufacturer, product
name and hardware/software version.
• Advertisement – Displays the advertisement status of the port. The possible field values
are:
– Enable – Enables advertisement on the port.
– Disable – Disables advertisement on the port.
The Port Information window contains the following fields:
Managed Address
• Address SubType – Displays the managed address subtype. For example, IPv4.
• Address – Displays the managed address.
• Interface SubType – Displays the port subtype.
• Interface Number – Displays the port number.
MAC/PHY Details
• Auto-Negotiation Supported – Displays the port speed auto-negotiation support status.
The possible values are:
– True – Indicates auto-negotiation is supported on the port.
– False – Indicates auto-negotiation is not supported on the port.
• Auto-Negotiation Enabled – Displays the port speed auto-negotiation active status. The
possible values are:
– True – Indicates auto-negotiation is enabled on the port.
– False – Indicates auto-negotiation is not enabled on the port.
