• Weighted Round Robin – Ensures that a single application does not dominate the device
forwarding capacity. Weighted Round Robin (WRR) forwards entire queues in a round robin
order. All queues can participate in WRR, except SP queues. If the traffic flow is minimal, and
SP queues do not occupy the whole bandwidth allocated to a port, the WRR queues can share
the bandwidth with the SP queues. This ensures that the remaining bandwidth is distributed
according to the weight ratio. If WRR is selected, the following weights are assigned to the
queues: 1, 2, 4, 8.
The CoS menu contains the following options:
• “Basic”
• “Advanced”
Basic
The CoS Basic menu contains the following options:
• “CoS Global Configuration”
• “CoS Interface Configuration”
• “Queue”
• “Bandwidth”
CoS Global Configuration
The CoS Global Configuration screen contains information for enabling QoS globally.
To configure CoS global parameters:
1. Click QoS > CoS > Basic > CoS Global Configuration. The CoS Global Configuration
screen displays:
