• Priority – Specifies the selected spanning tree instance device priority. The field range is
0-61440. The field default is 32768.
• VLAN ID – Maps the selected VLANs to the selected instance. Each VLAN belongs to
one instance.
• Bridge Identifer – Indicates the bridge ID of the selected instance.
• Designated Root – Indicates the priority and MAC address of the bridge with the lowest
path cost to the instance ID.
• Root Path Cost – Indicates the selected instance’s path cost.
• Root Port – Indicates the selected instance’s root port.
2. Select the MST ID and enter Priority field
3. Click APPLY to update the device.
MST Port Configuration
Network Administrators can assign MST port settings in the MST Port Configuration screen.
To define MST port settings:
1. Click Switching > STP > Advanced > MST Port Configuration. The MST Port
Configuration screen displays:
