FS728TP Smart Switch Software Administration Manual
Configuring Switching Settings 4-5
v1.1, September 2009
Basic
The LAG Basic menu contains the following options:
• “LAG Configuration”
• “LAG Membership”
LAG Configuration
The Basic LAG Configuration screen contains fields for configuring LAG parameters. The system
supports 8 LAGs, and each LAG can contain up to 8 ports.
To define LAG parameters:
1. Click Switching > LAG > Basic > LAG Configuration. The Basic LAG Configuration
screen displays:
The Basic LAG Configuration screen contains the following fields:
• Interface – Displays the LAG number.
• Description – Enter a user-defined LAG description.
• Status – Select the current link operation. The possible field values are:
Figure 4-2
