Smart Switch Software User Manual GS748T
4-2 Configuring the Switch
v1.0, October 2007
2. Select the row of the port that you want to configure. Then, at the top of screen, enter the
following information for the selected port:
• Type a description for the port in the Port Description field.
•From the Port Speed pull-down menu, select the rate for the port:
– 100M (100 Mbps)
– 10M (10 Mbps)
– Auto (Auto will set the speed to 1000Mbps)
– Disable (disable the port)
3. From the Duplex Mode pull-down menu, select the duplex mode for the port (this field is
available only when auto-negotiation is disabled and the port speed is set to 10M or 100M):
• Full (Full duplex)
• Half (Half duplex)
4. From the Flow Control pull-down menu, select whether or not to enable or disable Flow
Control.
5. From the Default Priority pull-down menu, assign a default packet priority for packets
without IEEE802.1P tagging. If the packet comes in with a priority tag, the priority is retrieved
from priority field of the tag.
6. Click Apply.
