User Manual

Configure System Information
78
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2
6. To view additional details about a port, click the name of the port in the Interface column of
the Port Information table.
The following table describes the detailed local information that displays for the selected
port.
System Capabilities The primary functions that the switch supports.
Interface The interface associated with the rest of the data in the row.
Port ID Subtype The type of information used to identify the interface in the Port ID field.
Port ID The port number.
Port Description The user-defined description of the port. For information about how to
configure the port description, see Configure Port Settings on page 93.
Advertisement The TLV advertisement status of the port.
Field Description
Managed Address
Address SubType The type of address the management interface uses, such as an IPv4
address.
Address The address used to manage the device.
Interface SubType The port subtype.
Interface Number The number that identifies the port.
MAC/PHY Details
Auto Negotiation Supported Indicates whether the interface supports port speed autonegotiation. The
possible values are True and False.
Auto Negotiation Enabled The port speed autonegotiation support status. The possible values are True
(enabled) or False (disabled).
Auto Negotiation Advertised
Capabilities
The port speed autonegotiation capabilities such as 100BASE-T half-duplex
mode or 10BASE-TX full-duplex mode.
Operational MAU Type The Medium Attachment Unit (MAU) type. The MAU performs physical layer
functions, including digital data conversion from the Ethernet interface
collision detection and bit injection into the network.
MED Details
Capabilities Supported The MED capabilities enabled on the port.
Current Capabilities The TLVs advertised by the port.
Device Class Network Connectivity indicates that the device is a network connectivity
device.
Field Description
