Configure System Information
62
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2
For information about setting up and configuring PoE timer schedules, see Set Up PoE
Timer Schedules on page 87.
12. Click the Apply button.
The updated configuration is sent to the switch. Configuration changes take effect
immediately.
The following table describes the nonconfigurable fields on the page.
Table 13. PoE Port Configuration
Field Description
High Power All ports supports high-power mode.
Max Power The maximum power in milliwatts that can be provided by the port.
Class The class defines the range of power that a powered device (PD) is drawing from
the switch. The class definitions are as follows:
• 0: 0.44–12.95W
• 1: 0.44–3.83W
• 2: 0.44–6.48W
• 3: 0.44–12.95W
• 4: 0.44–25.5W
Output Voltage The voltage that is delivered to the PD in volts.
Output Current The current that is delivered to the PD in mA.
Output Power The power that is delivered to the PD in watts.
Status The operational status of the port. The possible values are as follows:
• Disabled. No power is delivered.
• DeliveringPower. Power is being drawn by the PD.
• Fault. A problem occurred with the power.
• Test. The port is in test mode.
• otherFault. The port is idle because of an error condition.
• Searching. The port is not in one of the other states in this list.
Fault Status The error description when the PoE port is in a fault state. The possible values are
as follows:
• No Error. The port is not in any error state and can provide power.
• MPS Absent. The port detected the absence of the main power supply,
preventing the port from providing power.
• Short. The port detected a short circuit condition, preventing the port from
providing power.
• Overload. The PD that is connected to the port attempts to draw more power
than allowed by the port’s settings, preventing the port from providing power at
all.
• Power Denied. The port was denied power because of a shortage of power or
because of an administrative condition. In this condition, the port cannot
provide power.
