Configure System Information
49
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2
View the DayLight Saving Time Status
The Daylight Saving (DST) Status section shows information about the summer time settings
and whether the time shift for summer time is currently in effect.
To view the daylight saving time status:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 9.
The login window opens.
4. Enter the switch’s password in the Password field.
The default password is password.
The System Information page displays.
5. Select System > Management > Time > DayLight Saving Configuration.
6. To refresh the page, click the Update button.
Offset Specify the number of minutes to shift the summer time from the standard
time. The valid range is 1–1440 minutes.
Zone Specify the acronym associated with the time zone when summer time
is in effect. This field is not validated against an official list of time zone
acronyms.
Table 8. Daylight saving setting is Non Recurring (continued)
Field Description
