Specifications and Default Settings
317
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2
System Management Settings
The following table describes the system management settings.
Settings for Other Features
The following table describes the settings for other features.
Table 66. System management settings
Feature Sets Supported Default
Multi-session web connections 4 Enabled
SNMPv1/v2
SNMPv3
Max 5 community entries Enabled (read, read/write
communities)
Time control 1 (Local or SNTP) Local Time enabled
LLDP/LLDP-MED All ports Enabled
Logging 3 (Memory/Flash/Server) Memory Log enabled
MIB support 1 Disabled
Smart Control Center N/A Enabled
Statistics N/A N/A
Table 67. Settings for other features
Feature Sets Supported Default
IGMP snooping v1/v2/v3 All ports Disabled
Configurations upload/download 1 N/A
EAPoL flooding All ports Disabled
BPDU flooding All ports Disabled
Static multicast groups 32 None
Number of DHCP snooping
bindings
256 (total number for static and
dynamic bindings together)
N/A
