Specifications and Default Settings
316
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2
Quality of Service Settings
The following table describes the Quality of Service settings.
Security Settings
The following table describes the security settings.
Table 64. Quality of Service settings
Feature Sets Supported Default
Number of queues 8 N/A
802.1p 1 Enabled
DSCP 1 Disabled
Egress Rate limiting All ports Disabled
Table 65. Security settings
Feature Sets Supported Default
802.1X All ports Disabled
MAC ACL 100 (shared with IP and IPv6
ACLs)
All MAC addresses allowed
IP ACL 100 (shared with MAC and IPv6
ACLs)
All IP addresses allowed
Password control access 1 Idle timeout = 5 mins.
Password = password
Management security 1 profile with 20 rules for
HTTP/HTTPS/SNMP access to
allow/deny an IP address/subnet
All IP addresses allowed
Port MAC lock down All ports Disabled
