Specifications and Default Settings
315
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2
Port Characteristics
The following table describes the port characteristics.
Traffic Control Settings
The following table describes the traffic control settings.
Table 62. Port characteristics
Feature Sets Supported Default
Energy Efficient Ethernet (EEE) All ports Disabled
Auto negotiating speed and
full/half duplex
All ports Auto negotiation
Auto MDI/MDIX for cross over cables on all ports Enabled
802.3x flow control/back pressure 1 (per system) Disabled
Port mirroring: TX, RX, Both 1 Disabled
Port trunking (aggregation) 8 Preconfigured
802.1D spanning tree 1 Disabled
802.1w RSTP 1 Enabled
802.1s spanning tree 4 instances Disabled
Static 802.1Q tagging 256 VID = 1
Max member ports are equal to
the number of ports on the switch
Learning process Supports static and dynamic MAC
entries
Dynamic learning is enabled by
default
Table 63. Traffic control settings
Feature Sets Supported Default
Storm control All ports Disabled
Jumbo frame All ports Disabled
Max = 9216 bytes
