Monitor the System
259
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2
Packets Transmitted 65-127
Octets
The total number of packets (including bad packets) received that were between
65 and 127 octets in length inclusive (excluding framing bits but including FCS
octets).
Packets Transmitted 128-255
Octets
The total number of packets (including bad packets) received that were between
128 and 255 octets in length inclusive (excluding framing bits but including FCS
octets).
Packets Transmitted 256-511
Octets
The total number of packets (including bad packets) received that were between
256 and 511 octets in length inclusive (excluding framing bits but including FCS
octets).
Packets Transmitted
512-1023 Octets
The total number of packets (including bad packets) received that were between
512 and 1023 octets in length inclusive (excluding framing bits but including
FCS octets).
Packets Transmitted
1024-1518 Octets
The total number of packets (including bad packets) received that were between
1024 and 1518 octets in length inclusive (excluding framing bits but including
FCS octets).
Packets Transmitted > 1518
Octets
The total number of packets transmitted that were longer than 1518 octets
(excluding framing bits, but including FCS octets) and were otherwise well
formed. This counter supports a maximum increment rate of 815 counts per sec
at 10 Mb/s.
Maximum Frame Size The maximum Ethernet frame size the interface supports or is configured to use,
including Ethernet header, CRC, and payload. The possible range is 1518 to
9216. The default maximum frame size is 1518.
Total Packets Transmitted
Successfully
The number of frames that were transmitted by this port to its segment.
Unicast Packets Transmitted The total number of packets that higher-level protocols requested be transmitted
to a subnetwork-unicast address, including those that were discarded or not
sent.
Multicast Packets
Transmitted
The total number of packets that higher-level protocols requested be transmitted
to a multicast address, including those that were discarded or not sent.
Broadcast Packets
Transmitted
The total number of packets that higher-level protocols requested be transmitted
to the broadcast address, including those that were discarded or not sent.
Transmit Packets Discarded The number of outbound packets which were chosen to be discarded even
though no errors were detected to prevent them from being delivered to a
higher-layer protocol. A possible reason for discarding a packet could be to free
up buffer space.
Total Transmit Errors The sum of single, multiple, and excessive collisions.
Total Transmit Packets
Discarded
The sum of single collision frames discarded, multiple collision frames
discarded, and excessive frames discarded.
Single Collision Frames A count of the number of successfully transmitted frames on a particular
interface for which transmission is inhibited by exactly one collision.
Table 54. Detailed port statistics (continued)
Field Description
