User Manual

Monitor the System
255
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2
4. Enter the switch’s password in the Password field.
The default password is password.
The System Information page displays.
5. Select Monitoring > Ports > Port Detailed Statistics.
The following figure does not show all fields on the Port Detailed Statistics page.
6. From the Interface menu, select the interface with the statistics to view.
7. From the MST ID menu, select the MST ID associated with the interface (if available).
8. To refresh the page with the latest information about the switch, click the Update button.
9. To clear all the counters, click the Clear button. This resets all statistics for this port to the
default values.
The following table describes the detailed port information displayed on the page. To view
information about a different port, select the port number from the Interface menu.
Table 54. Detailed port statistics
Field Description
ifIndex This object indicates the ifIndex of the interface table entry associated with this
port on an adapter.
Port Type For normal ports this field displays Normal. Otherwise, the possible values are
as follows:
• Mirrored. This port is a participating in port mirroring as a mirrored port.
Look at the Port Mirroring pages for more information.
• Probe. This port is a participating in port mirroring as the probe port. Look
at the Port Mirroring pages for more information.
• Trunk Member. The port is a member of a link aggregation trunk. Look at
the Port Channel pages for more information.
