Monitor the System
251
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2
Receive Packets Discarded The number of inbound packets that were chosen to be discarded, even though
no errors were detected, in order to prevent their being delivered to a
higher-layer protocol. A possible reason for discarding a packet could be to free
up buffer space.
Octets Transmitted The total number of octets transmitted out of the interface, including framing
characters.
Packets Transmitted Without
Errors
The total number of packets transmitted out of the interface.
Unicast Packets Transmitted The total number of packets that higher-level protocols requested be transmitted
to a subnetwork-unicast address, including those that were discarded or not
sent.
Multicast Packets
Transmitted
The total number of packets that higher-level protocols requested be transmitted
to a multicast address, including those that were discarded or not sent.
Broadcast Packets
Transmitted
The total number of packets that higher-level protocols requested be transmitted
to the broadcast address, including those that were discarded or not sent.
Transmit Packets Discarded The number of outbound packets that were chosen to be discarded, even
though no errors were detected, in order to prevent their being delivered to a
higher-layer protocol. A possible reason for discarding a packet could be to free
up buffer space.
Most Address Entries Ever
Used
The highest number of Forwarding Database Address Table entries that were
learned by this switch since the most recent reboot.
Address Entries in Use The number of learned and static entries in the Forwarding Database Address
Table for this switch.
Maximum VLAN Entries The maximum number of VLANs allowed on this switch.
Most VLAN Entries Ever
Used
The largest number of VLANs that were active on this switch since the last
reboot.
Static VLAN Entries The number of active VLAN entries on this switch that were created statically.
VLAN Deletes The number of VLANs on this switch that were created and then deleted since
the last reboot.
Time Since Counters Last
Cleared
The elapsed time, in days, hours, minutes, and seconds, since the statistics for
this switch were last cleared.
Table 52. Switch statistics (continued)
Field Description
