Configure Rules for an Extended IP ACL
You can define rules for extended IP-based ACLs. The access list definition includes rules
that specify whether traffic that is matching the criteria is forwarded normally or discarded.
Note: An implicit deny all rule is included at the end of an ACL list. This
means that if an ACL is applied to a packet and if none of the explicit
rules match, then the final implicit deny all rule applies and the packet
is dropped.
Add a Rule for an Extended IP ACL
 To add a rule for an extended IP ACL:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 9.
The login window opens.
4. Enter the switch’s password in the Password field.
The default password is password.
The System Information page displays.
5. Select Security > ACL > Advanced > IP Extended Rules.
If no rules exists, the Extended ACL Rule Table shows the message No rules have been
configured for this ACL. If one or more rules exist for the ACL, the rules display in the
Extended ACL Rule Table.
6. From the ACL ID/Name menu, select the IP ACL for which you want to add a rule.
For extended IP ACLs, this must be an ID in the range from 100 to 199 or a name.
7. Click the Add button.
