The binding is removed.
The following table describes the nonconfigurable information on the page.
Configure an IP ACL
An IP ACL consists of a set of rules that are matched sequentially against a packet. When a
packet meets the match criteria of a rule, the specified rule action (Permit or Deny) is taken,
and the additional rules are not checked for a match. You must specify the interfaces to which
an IP ACL applies, as well as whether it applies to inbound or outbound traffic.
The following steps are involved in defining an IP ACL and applying it to the switch:
1. Create an IP ACL ID (see Configure an IP ACL on page 234).
2. Create an IP rule (see Configure Rules for a Basic IP ACL on page 236 or Configure
Rules for an Extended IP ACL on page 240).
3. Associate the IP ACL with one or more interfaces (see Configure IP ACL Interface
Bindings on page 244).
Add an IP ACL
 To add an IP ACL:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 9.
The login window opens.
4. Enter the switch’s password in the Password field.
The default password is password.
Table 49. MAC Binding Table
Field Description
Interface The interface of the ACL assigned.
Direction The selected packet filtering direction for the ACL.
ACL Type The type of ACL assigned to the selected interface and direction.
ACL ID The ACL name identifying the ACL assigned to the selected interface
and direction.
Sequence Number The sequence number signifying the order of the specified ACL relative
to other ACLs assigned to the selected interface and direction.
