User Manual

Manage Device Security
215
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2
4. Enter the switch’s password in the Password field.
The default password is password.
The System Information page displays.
5. Select Security > Traffic Control > Port Security > Port Security Configuration.
6. To enable port security on the switch, select the Port Security Mode Enable radio button.
The default is Disable.
7. Click the Apply button.
The updated configuration is sent to the switch. Configuration changes take effect
immediately.
8. Click the Update button to refresh the page with the latest information about the switch.
The Port Security Violations table shows information about violations that occurred on ports
that are enabled for port security. The fields are described in the following table.
Configure a Port Security Interface
A MAC address can be defined as allowable by one of two methods: dynamically or statically.
Both methods are used concurrently when a port is locked.
Dynamic locking implements a first arrival mechanism for port security. You specify how
many addresses can be learned on the locked port. If the limit was not reached, then a
packet with an unknown source MAC address is learned and forwarded normally. When the
limit is reached, no more addresses are learned on the port. Any packets with source MAC
addresses that were not already learned are discarded. You can effectively disable dynamic
locking by setting the number of allowable dynamic entries to zero.
Table 47. Port Security Violations information
Field Description
Port The physical interface.
Last Violation MAC The source MAC address of the last packet that was discarded at a locked port.
VLAN ID The VLAN ID corresponding to the last MAC address violation.
