Configure Quality of Service
177
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2
Discarded Packets A count of the total number of packets discarded for all class instances in this service
policy for any reason due to DiffServ treatment. This is the overall count per interface, per
direction. The discarded packets are supported in the inbound direction but not in the
outbound direction.
Member Classes List of all DiffServ classes currently defined as members of the selected policy name.
Select a member class name to display its statistics. If no class is associated with the
selected policy, then nothing is populated in the list.
Table 41. DiffServ Service Statistics information (continued)
Field Description
