User Manual

Configure Switching
150
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2
Set the Dynamic Address Aging Interval
You can set the address aging interval for the specified forwarding database.
 To set the address aging interval:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 9.
The login window opens.
4. Enter the switch’s password in the Password field.
The default password is password.
The System Information page displays.
5. Select Switching > Address Table > Advanced > Dynamic Addresses.
6. In the Address Aging Timeout (seconds) field, specify the time-out period in seconds for
aging out dynamically learned forwarding information.
802.1D-1990 recommends a default of 300 seconds. The value can be any number
between 10 and 1000000 seconds. The default is 300.
7. Click the Apply button.
Interface The interface upon which this address was learned.
Status The status of this entry. The meanings of the values are as follows:
• Static. The value of the corresponding instance was added by the
system or a user and cannot be relearned.
• Learned. The value of the corresponding instance was learned, and is
being used.
• Management. The value of the corresponding instance is also the
value of an existing instance of dot1dStaticAddress.
Table 36. MAC Address Table information (continued)
Field Description
