User Manual

Configure Switching
144
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2
The default password is password.
The System Information page displays.
5. Select Switching > Multicast > Static Multicast Address > Multicast Group
Configuration.
6. From the VLAN ID menu, select the VLAN ID.
7. In the Multicast Address field, enter the multicast MAC address that must become the
group identifier.
8. Click the Add button.
The multicast group is added.
The following table describes the nonconfigurable information on the page.
Remove a Static Multicast Group
You can remove a static multicast group that you no longer need. Because the multicast MAC
address is the multicast group identifier. You remove a static multicast group by removing the
static multicast address from the VLAN to which it is assigned.
 To remove one or more static multicast groups:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
Table 35. Multicast Group Configuration information
Field Definition
VLAN Name The VLAN name, if any, that is associated with the VLAN ID.
Type The type of multicast group, which is determined by the way in which
members are added to the group:
• Dynamic. Members are added dynamically to the multicast group.
By default, all groups are dynamic groups.
• Static. If you add static members to the multicast group (see
Configure Multicast Group Membership on page 145), the group
becomes a static group.
