Configure Switching
143
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2
The following table describes the nonconfigurable information on the page.
Configure a Static Multicast Group
You can configure up to 32 static multicast groups. You create a static multicast group by
adding a multicast MAC address to a VLAN. The multicast MAC address becomes the group
identifier.
To configure a static multicast group:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 9.
The login window opens.
4. Enter the switch’s password in the Password field.
Table 34. Querier VLAN Status information
Field Description
VLAN ID The VLAN ID on which IGMP snooping querier is administratively enabled
and the VLAN exists in the VLAN database.
Operational State The operational state of the IGMP snooping querier on a VLAN. It can be in
any of the following states:
• Querier. The snooping switch is the querier in the VLAN. The snooping
switch sends out periodic queries with a time interval equal to the
configured querier query interval. If the snooping switch finds a better
querier in the VLAN, it moves to non-querier mode.
• Non-Querier. The snooping switch is in non-querier mode in the VLAN.
If the querier expiry interval timer expires, the snooping switch moves
into querier mode.
• Disabled. The snooping querier is not operational on the VLAN. The
snooping querier moves to disabled mode when IGMP snooping is not
operational on the VLAN or when the querier address is not configured
or the network management address is also not configured.
Operational Version The operational IGMP protocol version of the querier.
Last Querier Address The IP address of the last querier from which a query was snooped on the
VLAN.
Last Querier Version The IGMP protocol version of the last querier from which a query was
snooped on the VLAN.
Operational Max Response Time Displays maximum response time to be used in the queries that are sent by
the snooping querier.
