Datasheet

Product GS105Ev2 GS105PE GS108Ev3 GS108PEv3 GS116Ev2 JGS516PE JGS524Ev2 JGS524PE
LEDs
Per port Speed, Link, Activity
Per device Power, Fan and PoE Power Status
PHYSICAL SPECIFICATIONS
Dimensions (mm) 94x100x27 158x100x27 158x101x29 158x101x29 286x101x26 328x170x43 328x170x43 328x170x43
Weight (kg) 0.25 0.47 0.50 0.54 0.84 1.67 1.40 1.84
Fan 0 0 0 0 0 1 0 1
POWER CONSUMPTION (WHEN ALL PORTS USED, LINE-RATE TRAFFIC AND MAX POE)
Worst case, all ports
used, line-rate trac,
max PoE (W)
2.6 22.0 4.5 60.0 10.0 110.0 13.8 123.0
Heat Dissipation
Max/Standby
(BTU/hr)
Max: 8.9
Min: 2.2
Max: 6.7
Min: 1.2
Max: 15.2
Min: 4.9
Max: 205.2
Min: 3.7
Max: 34.2
Min: 13.3
Max: 34.2
Min: 14.4
Max: 47.2
Min: 19.6
Max: 78.7
Min: 19.8
ENVIRONMENTAL SPECIFICATIONS
Operating
Operating
temperature
32° to 122°F (0° to 50°C)
Humidity 90% maximum relative humidity, non-condensing
Altitude 10,000  (3,000 m) maximum
Storage
Storage
temperature
– 4° to 158°F (–20° to 70°C)
Humidity 95% maximum relative humidity, non-condensing
Altitude 10,000  (3,000 m) maximum
Technical Specifications
ProSAFE® Gigabit Web Managed (Plus) Switches Data Sheet
Page 8 of 10
