Datasheet

FRONT REAR INTERNAL
Modelname Form-Factor
10/100/1000
Base-TRJ45ports
PoE802.3afPorts PowerSupply PoEbudget
GS105E Desktop 5 N/A External Power Adapter N/A
GS105PE Desktop 5 2
NO POWER SUPPLY - must
be powered from another
PoE device
PoE pass-thru: 19W with
802.3at/7.9W with
802.3af input power
GS108E Desktop 8 N/A External Power Adapter N/A
GS108PE Desktop 8 4 External Power Adapter 53W
GS116E Desktop 16 N/A External Power Adapter N/A
JGS516PE Rackmount 16 8 Internal 85W
JGS524E Rackmount 24 N/A Internal N/A
JGS524PE Rackmount 24 12 Internal 100W
Hardware at a Glance
Management
IP
Multicastltering
IEEE802.3az
Auto-EEE
VLANs QoS
PortTrunking
1
(Static
Manual
LAGsonly)
RateLimiting
Jumbo
FrameSupport
PC Utility Tool
Web GUI
IGMP Snooping
v1, v2 and v3
Yes
Port-based,
IEEE 802.1Q-based VLANs
Port-based,
IEEE 802.1p-based
16 & 24-port
models only
Yes Yes
Soware at a Glance
1
Static manual LAGs only; supported on 16-port and 24-port models only (GS116E, JGS516E, JGS524E, JGS524PE)
ProSAFE® Gigabit Web Managed (Plus) Switches Data Sheet
Page 2 of 10
