How to Set Up a Client-to-Gateway VPN Configuration
Setting up a VPN between a remote PC running the NETGEAR ProSafe VPN Client and a
network gateway involves the following two steps:
• “Step 1: Configuring the Client-to-Gateway VPN Tunnel on the DG834G v3” on page 7-7
uses the VPN Wizard to configure the VPN tunnel between the remote PC and network
gateway.
• “Step 2: Configuring the NETGEAR ProSafe VPN Client on the Remote PC” on page 7-12
configures the NETGEAR ProSafe VPN Client endpoint.
Step 1: Configuring the Client-to-Gateway VPN Tunnel on the
DG834G v3
The worksheet below identifies the parameters used in the following procedure. A blank
worksheet is at “Planning a VPN” on page 7-4.
Figure 7-3
Note: This section uses the VPN Wizard to set up the VPN tunnel using the VPNC
default parameters listed in Table 7-2 on page 7-5. If you have special requirements
not covered by these VPNC-recommended parameters, refer to “How to Set Up
VPN Tunnels in Special Circumstances” on page 7-38 to set up the VPN tunnel.
192.168.3.1
VPN Tunnel
DG834G
22.23.24.25
PC
(Running NETGEAR
ProSafe VPN Client)
PCs
0.0.0.0
