Quick Start Guide

You’re Done!
Congratulations! Your Arlo product is set up and ready to go.
To view tutorial videos, find troubleshooting tips, or get support, visit
support.arlo.com.
Ceiling and Wall Installation Kit
1 Plastic bracket for either drop ceiling mounting or wall mounting
2 Metal bracket for drop ceiling mounting
3 One metal T-bar for drop ceiling mounting
4 One lock screw to lock the T-bar for drop ceiling mounting
5 Four short screws to attach the metal bracket for drop ceiling mounting
6 Four tall screws to attach the plastic bracket for wall mounting
7 Four anchors for the tall screws for wall mounting
8 Four rubber feet for desk installation
4
5
6
7
8
1
2
3
Drop Ceiling Installation
If you are mounting the base station on a hard ceiling instead of a ceiling bar
that is typical for a drop ceiling, use the wall installation instructions.
1. Slide the T-bar partially into the metal bracket and attach the metal
bracket to the ceiling bar.
Then push the T-bar over the ceiling bar and use the lock screw to lock
the metal bracket into place.
2. Making sure that the two protruding hooks on the plastic bracket are
facing down, place the plastic bracket against the metal bracket and
align the four inner holes of the plastic bracket with the four holes of
the metal bracket.
3. Then insert the four short screws and secure the plastic bracket onto
the metal bracket.
Hold the base station upside down, with the bottom facing the plastic
bracket that is attached to the metal bracket, and align the two
rectangular holes in the bottom of the base station with the protruding
hooks on the plastic bracket
4. Push the hooks into the holes and turn the base station to secure it onto
the plastic bracket.
Result
Wall Installation
1. Place the plastic bracket on the wall where you want to mount the base
station.
2. Mark the wall where the four outer mounting holes are.
3. Using the wall anchors and tall screws, attach the mounting bracket to
the wall.
4. Align the two rectangular holes in the bottom of the base station with
the protruding hooks on the plastic bracket.
5. Push the hooks into the holes and turn the base station to secure it onto
the plastic bracket.
