User Guide

Clear Spot 4G+ User Guide
34 2131352
Using the Power Button to Determine the Device State
The power button on the device also indicates the device's status, as shown in
the following table.
Controlling the Device Using the Power Button
Power button
Description Your action
Not lit • The device is turned off, and may or
may not be charging.
• The device is turned on, but you have
turned off the LED.
• To turn the device on, press and hold the
power button for two seconds.
• [OPTIONAL]: Turn on the LED. See
"Enabling and Disabling the LED" on
page 72
.
Lit, flashing
(approximately every
4 seconds)
The device is turned on, and the LED is
enabled.
No action required.
Lit, flashing
(approximately every
30 seconds)
The device is in standby (low power) mode.
The following are off: LCD, Wi-Fi radio, 3G/
4G radios.
For more information, see
"Standby (Low
Power) Mode" on page 56
.
To exit standby mode:
Connect the device to the power adapter or
computer, through the USB cable.
— or —
Press the power button .
Type of press Result
Quick press • The device leaves standby (low power) mode.
• The LCD wakes up (turns on) if it was enabled but dormant. (The LCD turns dark,
after a configurable time of inactivity.)
• A displayed message is confirmed or acknowledged.
• Display of the Wi-Fi network name (SSID) and password is turned off.
Quick double-press • The LCD wakes up (turns on) if it was enabled but dormant. (The LCD turns dark,
after a configurable time of inactivity.)
• The Wi-Fi network name (SSID) and password are briefly displayed. See "Wi-Fi
Password Reminder" on page 88
.
Long press (press and hold
for two seconds)
The device turns on or off.
