Supplemental Information
77
N300 Wireless Router
Technical Specifications
Table 5. Router specifications
Feature Description
Data and routing protocols TCP/IP, RIP-1, RIP-2, DHCP, PPPoE, PPTP, Bigpond, Dynamic DNS, UPnP, and
SMB
Power adapter • North America:
120V, 60 Hz, input
• UK,
Australia: 240V, 50 Hz, input
• Europe: 230V
, 50 Hz, input
• All regions (output): 12 VDC @ 1A, output
Dimensions 217.74 x 147.73 x 34.92 mm (8.57 x 5.81 x 1.37 in.)
Weight 0.41 kg (0.91 lb)
Operating temperature 0° to 40°C (32º to 104ºF)
Operating humidity 90% maximum relative humidity, noncondensing
Electromagnetic emissions FCC Part 15 Class B
VCCI Class B
EN 55 022 (CISPR 22), Class B C-Tick N10947
LAN 10BASE-T or 100BASE-Tx, RJ-45
WAN 10BASE-T or 100BASE-Tx, RJ-45
Wireless Maximum wireless signal rate complies with the IEEE 802.11 standard. See the
entry for
Transmission speed in Table 4 on page 76.
Radio data rates Auto Rate Sensing
Data encoding standards IEEE 802.11n version 2.0
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b 2.4 GHz
Maximum computers per
wireless network
Limited by the amount of wireless network traffic generated by each node
(typically 50–70 nodes)
Operating frequency range 2.412–2.462 GHz (US)
2.412–2.472 GHz (Japan)
2.412–2.472 GHz (Europe ETSI)
802.11 security WEP, WPA-PSK, WPA2-PSK, WPA-PSK + WPA2-PSK mixed mode,
WPA/WPA2 Enterprise
Wireless
(continued)
20/40 MHz coexistence Enabled
Data rate Best
Output power Full
Table 4. Router factory default settings (continued)
Feature Default Behavior
