Interfaces
Figure 2 – Interfaces
Item Description
Antenna panel Includes 2 x pairs Cross polarised antennas and GPS antenna
Smart Antenna Tool port Connect the Smart Antenna Tool here
SIM hatch Open the hatch to insert SIM here
Antenna Power Supply port (PoE) Provides power and data connectivity to the CFW-2182 with
Ethernet cable
Table 2 – Interfaces
Antenna panel
Smart Antenna
Tool port with
tool in place
SIM card
access hatch
Antenna Power
Supply port (PoE)
