Item Definition
WWAN connection status
Profile name The name of the currently active profile.
Status The connection status of the currently active profile.
Default profile Indicates whether the current profile in use is the default profile.
WWAN IP The IP address assigned by the mobile broadband carrier network.
DNS server The primary and secondary DNS servers for the WWAN connection.
APN The Access Point Name currently in use.
Connection uptime The length of time of the current mobile connection session.
Advanced status
Mobile country code The Mobile Country Code (MCC) of the mobile network operator.
Mobile network code The Mobile Network Code (MNC) of the mobile network operator.
SIM ICCID The Integrated Circuit Card Identifier of the SIM card used with the CFW, a
unique number up to 19 digits in length.
Tracking Area Code
(TAC)
Identifies a tracking area within a particular network.
IMSI The International Mobile Subscriber Identity is a unique identifier of the user of
a cellular network.
Cell ID A unique code that identifies the base station from within the location area of
the current mobile network signal.
Channel number The number assigned to the frequency of the current cellular connection.
Reference Signal
Received Quality
(RSRQ)
RSRQ calculates signal quality taking into consideration the RSSI.
It is calculated by N x RSRP / RSSI where N is the number of Physical Resources
Blocks (PRBs) over which the RSSI is measured.
Reference Signal
Received Power (RSRP)
A cell-specific reference signal used to determine RSRP.
Packet service status Displays whether the packet service is Attached or Detached.
When APN or username/password is changed, the device detaches and
reattaches to the network.
Cell Information
PCI Physical Cell Identity is used to identify a cell based on a combination of its
Primary Synchronization Signal (PSS) and (Secondary Synchronization Signal
(SSS).
EARFCN The absolute radio-frequency channel number (ARFCN) is a code that identifies
the physical radio uplink/downlink channel pair used for transmission and
reception.
