The Status page shows System information, LAN details, Cellular connection status, WWAN connection status,
Advanced status and Cell information details.
You can toggle the sections from view by clicking the or buttons to expand or collapse the amount of
information displayed for each.
The following table contains a description of each of the items on the Status page.
Item Definition
System information
System up time The current uptime of the CFW.
Hardware version The hardware version of the CFW.
Serial Number The serial number of the CFW.
Firmware version The firmware version of the CFW
Model The type of phone module and the firmware version of the module.
Module firmware The firmware revision of the phone module.
IMEI The International Mobile Station Equipment Identity number used to uniquely
identify a mobile device.
Hardware A hardware identifier.
LAN
IP The IP address and subnet mask of the CFW.
MAC address The MAC address of the CFW.
Ethernet port status Displays the current status of the Ethernet port and its operating speed.
Cellular connection status
SIM Status Displays the activation status of the CFW on the carrier network.
Signal strength (dBm) The current signal strength measured in dBm
Network registration
status
The status of the CFW’s registration for the current network.
Operator selection The mode used to select an operator network.
Current operator The current operator network in use.
Roaming status The roaming status of the CFW.
Allowed bands The bands to which the CFW may connect.
Current band The current band being used by the CFW.
Coverage The type of mobile coverage being received by the CFW.
