Advanced
YML717 Rev1 NetComm NB5 Ethernet/USB Modem Router
www.netcomm.com.au 71
Status Menu
About: The Status Menu provides dynamically-updated information about your DSL connection,
modem and network performance.
Network Statistics
To access network statistics, click on Status>Network Statistics.
Select Network Interface type to peruse statistics for each type of connection.
Connection Status
To access Connection Status, click on Status>Connection Status.
This display summarizes the status of the current active connection
DHCP Clients
TO access DHCP Clients, click on Status>DHCP Clients
This display indicates the MAC address, IP address, Host Name and lease time for each DHCP client
connected to the NB5.
Modem Status
To access Modem Status, click on Status>Modem Status.
This displays Upstream (=Us) and Downstream (=Ds) connection speed in Kbps.
Product Information
To access Product Information, click on Status>Product Information.
This displays various parameters of the NB5 including Firmware Version
System Log
To access the System Log, click on Status>System Log
This maintains a dynamic display of System Log information.
