Connection
NetComm NB5 Ethernet/USB Modem Router YML717 Rev1
20 www.netcomm.com.au
Step 1.2 Connecting to the ADSL Line
Connect your ADSL Router to the ADSL line with the telephone cable. If you are connect-
ing a telephone or facsimile to the same line, refer to the section on Microfilters for more
information.
Step 1.3 Connecting to the Power Outlet
Connect your ADSL Router to the Power Outlet via the Power adapter (that comes with
your ADSL Router package).
Step 1.4 Powering On
Power on the Power Outlet that is connected to your ADSL Router.
Power on your Computer(s)/Notebook(s).
Please proceed to Step 2.
