Datasheet

Specifications

General

Dimensions 3.8 in x 7.7 in x 1.6 in (9.7 cm x 19.6 cm x 4.1 cm)

Weight 18 oz (0.51 kg)

Battery Rechargeable lithium-ion battery pack (3.6 V, 6 Ah, 21 Wh)

Battery Life Typical operating life is 4 hours. Typical charge time is 7 hours.

Display 5.0 in color LCD with capacitive touch screen (480 x 800 pixels)

Keypad 1-key elastometric (power only)

Host Interface Micro USB On-the-Go port

USB Port USB 2.0 Type A port

SD Card Slot Supports Micro SD

Cable Test Pair length, crossed, reversed and distance to open, short, split

Tone Generator Digital tone: [455 KHz]; Analog tones: [400 Hz, 1KHz]

Ports RJ-45 copper port 10/100/1000BASE-T. 100/1000BASE-X. Fiber adapter port. Fiber port supports

standard SFP

External AC Adapter/

Charger

AC input 90-264 Vac 48-62 Hz input power DC output 15 Vdc at 2 amps or RJ-45 via PoE

Environmental

Operating Temperature 32°F to 113°F (0°C to +45°C)

NOTE: The battery will not charge if the internal temperature of the tester is above 122°F (50°C)

Operating relative

humidity (% RH without

condensation)

90% (50°F to 95°F; 10°C to 35°C)

75% (95°F to 113°F; 35°C to 45°C)

Shock and vibration 1 m drop test, Random, 3.8 grms, 5 Hz-500 Hz (Class 2)

Safety IEC 61010-1:2010: Pollution degree 2

Altitude 4,000 m; Storage: 12,000 m

EMC IIEC 61326-1:2013: Basic Electromagnetic Environment; CISPR 11: Group 1, Class A

Certifications and Compliance

Conforms to relevant European Union directives

Conforms to relevant Australian Safety and EMC standards.

Complies with 47 CFR Part 15 requirements of the U.S. Federal Communications Commission.

Conforms to relevant South Korean EMC Standards.

Additional South Korean EMC Standards Information

Electromagnetic Compatibility. Applies to use in Korea only. Class A Equipment (Industrial Broadcasting & Communications Equipment) [1]

[1] This product meets requirements for industrial (Class A) electromagnetic wave equipment and the seller or user should take notice of it. This

equipment is intended for use in business environments and is not to be used in homes.

LRG2-DS-20-V1
