Portable Projector NP215/NP210/NP115/NP110 User’s Manual The NP210 and NP115 are not distributed in North America.
1st edition, August 2009 • DLP and BrilliantColor are trademarks of Texas Instruments. • IBM is a trademark or registered trademark of International Business Machines Corporation. • Macintosh, Mac OS X and PowerBook are trademarks of Apple Inc., registered in the U.S. and other countries. • Microsoft, Windows, Windows Vista, and PowerPoint are either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries.
Important Information Safety Cautions Precautions Please read this manual carefully before using your NEC NP215/NP210/NP115/NP110 projector and keep the manual handy for future reference. CAUTION To turn off main power, be sure to remove the plug from power outlet. The power outlet socket should be installed as near to the equipment as possible, and should be easily accessible. CAUTION TO PREVENT SHOCK, DO NOT OPEN THE CABINET. THERE ARE HIGH-VOLTAGE COMPONENTS INSIDE.
Important Information RF Interference (for USA only) WARNING The Federal Communications Commission does not allow any modifications or changes to the unit EXCEPT those specified by NEC Display Solutions of America, Inc. in this manual. Failure to comply with this government regulation could void your right to operate this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Important Information Place the projector in a horizontal position The tilt angle of the projector should not exceed 10 degrees, nor should the projector be installed in any way other than the desktop and ceiling mount, otherwise lamp life could decrease dramatically. 10˚ Fire and Shock Precautions • Ensure that there is sufficient ventilation and that vents are unobstructed to prevent the build-up of heat inside your projector. Allow at least 4 inches (10cm) of space between your projector and a wall.
Important Information - If the projector does not operate normally when you follow the instructions described in this user's manual. - If the projector has been dropped or the cabinet has been damaged. - If the projector exhibits a distinct change in performance, indicating a need for service. • Disconnect the power cable and any other cables before carrying the projector. • Turn off the projector and unplug the power cable before cleaning the cabinet or replacing the lamp.
Important Information CAUTION: • DO NOT TOUCH THE LAMP immediately after it has been used. It will be extremely hot. Turn the projector off and then disconnect the power cable. Allow at least one hour for the lamp to cool before handling. • When removing the lamp from a ceiling-mounted projector, make sure that no one is under the projector. Glass fragments could fall if the lamp has been burned out. Note for US Residents The lamp in this product contains mercury.
Table of Contents Important Information. ...........................................................................................i 1. Introduction........................................................................................................... 1 1 What’s in the Box?.......................................................................................................... 1 Introduction to the Projector...........................................................................................
Table of Contents 4. Convenient Features. .................................................................................... 28 1 Turning off the Image and Sound................................................................................. 28 2 Freezing a Picture........................................................................................................ 28 Enlarging a Picture.......................................................................................................
1. Introduction 1 What’s in the Box? Make sure your box contains everything listed. If any pieces are missing, contact your dealer. Please save the original box and packing materials if you ever need to ship your projector.
1. Introduction Introduction to the Projector This section introduces you to your new projector and describes the features and controls. Congratulations on Your Purchase of the Projector This DLP™ projector is one of the very best projectors available today. The projector enables you to project precise images up to 300 inches (measured diagonally) from your PC or Macintosh computer (desktop or notebook), VCR, DVD player or document camera.
1. Introduction About this user's manual The fastest way to get started is to take your time and do everything right the first time. Take a few minutes now to review the user's manual. This may save you time later on. At the beginning of each section of the manual you'll find an overview. If the section doesn't apply, you can skip it. In this user's manual the drawings of the projector show an example of NP215.
1. Introduction Part Names of the Projector Front/Top Zoom Lever (→ page 22) Controls (→ page 5) Focus Ring (→ page 22) Remote Sensor (→ page 7) Ventilation (outlet) Heated air is exhausted from here. Ventilation (inlet) Lens Built-in Security Slot ( Adjustable Tilt Foot Lever (→ page 21) Adjustable Tilt Foot (→ page 21) * Lens Cap )* Security chain opening Attach an anti-theft device. The security chain opening accepts security wires or chains up to 0.18 inch/4.6 mm in diameter.
1. Introduction Top Features 7 8 9 10 5 6 1 2 3 4 6. SOURCE Button (→ page 19) 1. POWER Button (ON / STAND BY) ( ) (→ page 17, 26) 7. MENU Button (→ page 39) 2. POWER Indicator (→ page 16, 17, 26, 68) 3. STATUS Indicator (→ page 68) 8. △▽◁▷ / Keystone △▽ / Volume ◁▷ Buttons (→ page 23, 25, 28) 4. LAMP Indicator (→ page 65, 68) 9. ENTER Button 5. AUTO ADJ. Button (→ page 25) 10. EXIT Button Terminal Panel Features NP215 1 2 3 4 5 6 2 3 4 5 6 7 NP210/NP115/NP110 1 1.
1. Introduction Part Names of the Remote Control 1 3 2 7 5 6 10 12 4 8 9 11 14 15 ＋ 18 19 20 23 29 10. VIEWER Button (not available on this series of projectors) 13 16 17 22 24 21 25 26 11. ID SET Button (→ page 56) 12. Numeric Keypad Button/CLEAR Button (→ page 56) 13. FREEZE Button (→ page 28) 14. AV-MUTE Button (→ page 28) 15. MENU Button (→ page 39) 16. EXIT Button (→ page 39) 27 28 17. Button (→ page 39) 18. ENTER Button (→ page 39) 19. MAGNIFY (+)(–) Button (→ page 28) 20.
1. Introduction Battery Installation 1 Press firmly and slide the battery cover off. 2 Install new batteries (AAA). Ensure that you have the batteries’ polarity (+/−) aligned correctly. 3 Slip the cover back over the batteries until it snaps into place. Do not mix different types of batteries or new and old batteries. EN OP OP EN Remote Control Precautions • • • • • • • • Handle the remote control carefully. If the remote control gets wet, wipe it dry immediately.
2. Installation and Connections This section describes how to set up your projector and how to connect video and audio sources. Your projector is simple to set up and use. But before you get started, you must first: 1 ① Set up a screen and the projector. ② Connect your computer or video equipment to the projector. See pages 11, 12, 13, 14, 15. ③ Connect the supplied power cable. See page 16. NOTE: Ensure that the power cable and any other cables are disconnected before moving the projector.
2. Installation and Connections Throw Distance and Screen Size The following shows the proper relative positions of the projector and screen. Refer to the table to determine the position of installation. Distance Chart C Screen center B Screen bottom D 2.
2. Installation and Connections Reflecting the Image WARNING * Installing your projector on the ceiling must be done by a qualified technician. Contact your NEC dealer for more information. * Do not attempt to install the projector yourself. • Only use your projector on a solid, level surface. If the projector falls to the ground, you can be injured and the projector severely damaged. • Do not use the projector where temperatures vary greatly.
2. Installation and Connections Making Connections Connecting Your PC or Macintosh Computer NOTE: When using with a notebook PC, be sure to connect the projector and notebook PC while the projector is in standby mode and before turning on the power to the notebook PC. In most cases the output signal from the notebook PC is not turned on unless connected to the projector before being powered up.
2. Installation and Connections Connecting an External Monitor COMPUTER OUT VGA signal cable (not supplied) VGA signal cable (supplied) PHONE You can connect a separate, external monitor to your projector to simultaneously view on a monitor the computer analog image you’re projecting. NOTE: Daisy chain connection is not possible.
2. Installation and Connections Connecting Your DVD Player with Component Output COMPUTER IN AUDIO IN Optional 15-pin - to - RCA (female) ×3 cable (ADP-CV1E) Stereo mini plug - to - RCA audio cable (not supplied) Audio Equipment Component video RCA×3 cable (not supplied) AUDIO IN L R DVD player Y Cb Cr Component L R AUDIO OUT Audio cable (not supplied) NOTE: Refer to your DVD player's owner's manual for more information about your DVD player's video output requirements.
2. Installation and Connections Connecting Your VCR S-VIDEO IN VIDEO IN AUDIO IN S-Video cable (not supplied) Stereo mini plug - to - RCA audio cable (not supplied) Video cable (not supplied) Audio equipment VCR L R AUDIO OUT VIDEO S-VIDEO AUDIO IN VIDEO OUT L R Audio cable (not supplied) NOTE: Refer to your VCR owner's manual for more information about your equipment's video output requirements.
2. Installation and Connections Connecting to a Network (NP215 only) The projector comes standard with a LAN port (RJ-45) which provides a LAN connection using a LAN cable. Using a LAN cable allows you to specify the Network Settings and the Alert Mail Settings for the projector over a LAN. To use a LAN connection, you are required to assign an IP address to the projector on the [PROJECTOR NETWORK SETTINGS] screen of the web browser on your computer. For setting, see page 36, 37, 38.
2. Installation and Connections Connecting the Supplied Power Cable Connect the supplied power cable to the projector. First connect the supplied power cable's three-pin plug to the AC IN of the projector, and then connect the other plug of the supplied power cable in the wall outlet. The projector will go into standby mode. When in standby mode, the POWER indicator will light orange and the STATUS indicator will light green when [NORMAL] is selected for [STANDBY MODE].
3. Projecting an Image (Basic Operation) This section describes how to turn on the projector and to project a picture onto the screen. Turning on the Projector 1. Remove the lens cap • Do not remove the lens cap by pulling on the string. Doing so can cause mechanical damage to the part around the lens. 2. Press the (POWER) button on the projector cabinet or the POWER ON button on the remote control for 1 second. The POWER indicator will turn to green and the projector will become ready to use.
3. Projecting an Image (Basic Operation) Note on Startup screen (Menu Language Select screen) When you first turn on the projector, you will get the Startup menu. This menu gives you the opportunity to select one of the 21 menu languages. To select a menu language, follow these steps: 1. Use the , , or button to select one of the 21 languages from the menu. ＋ ＋ 2. Press the ENTER button to execute the selection. After this has been done, you can proceed to the menu operation.
3. Projecting an Image (Basic Operation) Selecting a Source Selecting the computer or video source NOTE: Turn on the computer or video source equipment connected to the projector. Selecting from Source List Press and quickly release the SOURCE button on the projector cabinet to display the Source list. Each time the SOURCE button is pressed, the input source will change as follows: “COMPUTER”, ”VIDEO”, “S-VIDEO”. To display the selected source, press the ENTER button or allow 2 seconds to elapse.
3. Projecting an Image (Basic Operation) Adjusting the Picture Size and Position Use the adjustable tilt foot, the zoom lever or the focus ring to adjust the picture size and position. In this chapter drawings and cables are omitted for clarity.
3. Projecting an Image (Basic Operation) Adjust the Tilt Foot 1. Lift the front edge of the projector. CAUTION: Do not try to touch the ventilation outlet during Tilt Foot adjustment as it can become heated while the projector is turned on and after it is turned off. 2. Push up and hold the Adjustable Tilt Foot Lever on the front of the projector to extend the adjustable tilt foot. 3. Lower the front of the projector to the desired height. 4.
3. Projecting an Image (Basic Operation) Zoom Use the ZOOM lever to adjust the image size on the screen. Zoom Lever Focus Use the FOCUS ring to obtain the best focus.
3. Projecting an Image (Basic Operation) Correcting Keystone Distortion Correcting Keystone Distortion If the screen is tilted vertically, keystone distortion becomes large. Proceed with the following steps to correct keystone distortion NOTE: • The Keystone correction can cause an image to be slightly blurred because the correction is made electronically. • The Keystone correction range can be made narrower, depending on a signal or its aspect ratio selection. Adjusting with buttons on the cabinet 1.
＋ 0 ID SET CLEAR AV-MUTE FREEZE MENU EXIT G MA NI Adjusting with the remote control GE ENTER 3. Projecting an Image (Basic Operation) PA FY L-CLICK 1. Press the KEYSTONE button. MOUSE R-CLICK ECO MODEKEYSTONEPICTURE The Keystone bar will be displayed. HELP FOCUS ASPECT VOL. ZOOM 2. Use the or button to correct the keystone distortion. Adjust so that the right and left sides are parallel. ON POWER OFF AUTO ADJ.
3. Projecting an Image (Basic Operation) Optimizing Computer Signal Automatically Adjusting the Image Using Auto Adjust Optimizing a computer image automatically. Press the AUTO ADJ. button to optimize a computer image automatically. This adjustment may be necessary when you connect your computer for the first time. [Poor picture] ＋ [Normal picture] NOTE: Some signals may take time to display or may not be displayed correctly. • The Auto Adjust function will work for computer (RGB) signal only.
3. Projecting an Image (Basic Operation) 7 Turning off the Projector To turn off the projector: 1. First, press the (POWER) button on the projector cabinet or the POWER OFF button on the remote control. The [POWER OFF / ARE YOU SURE? /CARBON SAVINGS- SESSION 0.000[g-CO2]] message will appear. 2. Secondly, press the ENTER button or press the (POWER) or the POWER OFF button again. The lamp will turn off and the projector will go into standby mode.
3. Projecting an Image (Basic Operation) After Use Preparation: Make sure that the projector is turned off. 1. Disconnect any other cables. 2. Retract adjustable tilt foot if extended. 3. Cover the lens with the lens cap.
4. Convenient Features 1 Turning off the Image and Sound Press the AV-MUTE button to turn off the image and sound for a short period of time. Press again to restore the image and sound. NOTE: Even though the image is turned off, the menu still remains on the screen. ＋ 2 Freezing a Picture Press the FREEZE button to freeze a picture. Press again to resume motion. NOTE: The image is frozen but the original video is still playing back. ＋ Enlarging a Picture You can enlarge the picture up to four times.
4. Convenient Features Changing Eco Mode This feature enables you to select two brightness modes of the lamp: OFF and ON modes. The lamp life can be extended by turning on the [ECO MODE]. [ECO MODE] Description Status of LAMP indicator [OFF] This is the default setting (100% Brightness). Off LAMP STATUS [ON] Select this mode to increase the lamp life (approx. 90% Brightness.) Steady Green ONlight POWER OFF AUTO ADJ. COMPUTER 1 2 VIDEO To turn on the [ECO MODE], do the following: 1.
4. Convenient Features 5 Checking Energy-Saving Effect [CARBON METER] This feature will show energy-saving effect in terms of CO2 emission reduction (kg) when the projector’s [ECO MODE] is set to [ON]. This feature is called as [CARBON METER]. There are two messages: [TOTAL CARBON SAVINGS] and [CARBON SAVINGS-SESSION]. The [TOTAL CARBON SAVINGS] message shows the total amount of CO2 emission reduction from the time of shipment up to now. You can check the information on [USAGE TIME] from [INFO.
4. Convenient Features 6 Preventing the Unauthorized Use of the Projector [SECURITY] A keyword can be set for your projector using the Menu to avoid operation by an unauthorized user. When a keyword is set, turning on the projector will display the Keyword input screen. Unless the correct keyword is entered, the projector cannot project an image. • The [SECURITY] setting cannot be cancelled by using the [RESET] of the menu. To enable the Security function: 1. Press the MENU button.
4. Convenient Features 7. Type in the same combination of buttons and press the ENTER button. The confirmation screen will be displayed. 8. Select [YES] and press the ENTER button. The SECURITY function has been enabled. To turn on the projector when [SECURITY] is enabled: 1. Press and hold the POWER button for about 1 second. The projector will be turned on and display a message to the effect that the projector is locked. 2. Press the MENU button. 3.
4. Convenient Features To disable the SECURITY function: 1. Press the MENU button. The menu will be displayed. 2. Select [SETUP] → [INSTALLATION] → [SECURITY] and press the ENTER button. The OFF/ON menu will be displayed. 3. Select [OFF] and press the ENTER button. The KEYWORD CONFIRMATION screen will be displayed. 4. Type in your keyword and press the ENTER button. When the correct keyword is entered, the SECURITY function will be disabled. NOTE: If you forget your keyword, contact your dealer.
4. Convenient Features 7 Using the Optional Remote Mouse Receiver (NP01MR) The optional remote mouse receiver enables you to operate your computer’s mouse functions from the remote control. It is a great convenience for clicking through your computer-generated presentations. Connecting the remote mouse receiver to your computer If you wish to use the remote mouse function, connect the mouse receiver and computer. The mouse receiver can be connected directly to the computer’s USB port (type A).
4. Convenient Features Operating your computer’s mouse from the remote control You can operate your computer’s mouse from the remote control. PAGE / Button: scrolls the viewing area of the window or to move to the previous or next slide in PowerPoint on your computer. Buttons: moves the mouse cursor on your computer. MOUSE L-CLICK Button: works as the mouse left button. MOUSE R-CLICK Button: works as the mouse right button.
4. Convenient Features 8 Network Setting by Using an HTTP Browser (NP215 only) Overview Connecting the projector to a network allows the Alert Mail setting (→ page 38) and the projector control from a computer via the network. To perform the projector control from a web browser, you must have an exclusive application installed on your computer. The IP address and subnet mask of the projector can be set on the Network Setting screen of the web browser by using an HTTP server function.
4. Convenient Features Network Settings http:// /index.html DHCP ����������������������������������Enabling this option automatically assigns an IP address to the projector from your DHCP server. Disabling this option allows you to register the IP address or subnet mask number obtained from your network administrator. TIP: You can check the IP address in the menu when [ENABLE] is selected for [DHCP]. To do so, from the menu, select [INFO.
4. Convenient Features Alert Mail Setting http:///lanconfig.html This option notifies your computer of an error message via e-mail when using wired LAN. An error message notification will be sent when the projector lamp has reached the end of its usable life or an error occurs in the projector. HOST NAME ���������������������������� Type in the hostname of the network connected to the projector. Up to 60 alphanumeric characters can be used.
5. Using On-Screen Menu Using the Menus NOTE: The on-screen menu may not be displayed correctly while interlaced motion video image is projected. 1. Press the MENU button on the remote control or the projector cabinet to display the menu. NOTE: The commands such as ENTER, EXIT, , in the bottom show available buttons for your operation. 2. Press the buttons on the remote control or the projector cabinet to display the submenu. 3.
5. Using On-Screen Menu 2 Menu Elements Tab Slide bar Solid triangle Available buttons Source Highlight Radio button High Altitude symbol Thermometer symbol Key Lock symbol Off Timer remaining time Menu windows or dialog boxes typically have the following elements: Highlight �����������������������������Indicates the selected menu or item. Solid triangle ����������������������Indicates further choices are available. A highlighted triangle indicates the item is active.
5. Using On-Screen Menu 3 List of Menu Items Some menu items are not available depending on the input source.
5. Using On-Screen Menu LAMP LIFE REMAINING LAMP HOURS USED TOTAL CARBON SAVINGS SOURCE NAME HORIZONTAL FREQUENCY VERTICAL FREQUENCY SIGNAL TYPE SOURCE VIDEO TYPE SYNC TYPE SYNC POLARITY SCAN TYPE PROJECTOR NAME IP ADDRESS WIRED LAN SUBNET MASK (NP215 only) GATEWAY MAC ADDRESS PRODUCT SERIAL NUMBER FIRMWARE VERSION DATA CONTROL ID (when [CONTROL ID] is set) CURRENT SIGNAL ALL DATA NETWORK SETTINGS (NP215 only) CLEAR LAMP HOURS USAGE TIME INFO.
5. Using On-Screen Menu 4 Menu Descriptions & Functions [SOURCE] COMPUTER Selects the computer connected to your COMPUTER IN input connector. NOTE: • When the component input signal is connected to the COMPUTER IN connector, select [COMPUTER]. • The projector will determine if the input signal is RGB or component signal. VIDEO Selects what is connected to your VIDEO input-VCR, DVD player or document camera. S-VIDEO Selects what is connected to your S-VIDEO input-VCR or DVD player.
5. Using On-Screen Menu 5 Menu Descriptions & Functions [ADJUST] [PICTURE] [PRESET] This function allows you to select optimized settings for your projected image. You can adjust neutral tint for yellow, cyan or magenta. There are six factory presets optimized for various types of images. You can also use [DETAIL SETTINGS] to set user adjustable settings to customize each gamma or color. Your settings can be stored in [PRESET 1] to [PRESET 6].
5. Using On-Screen Menu Selecting Gamma Correction Mode [GAMMA CORRECTION] Each mode is recommended for: DYNAMIC �������������� Creates a high-contrast picture. NATURAL ��������������� Natural reproduction of the picture. BLACK DETAIL ������� Emphasizes detail in dark areas of the picture. Adjusting Color Temperature [COLOR TEMPERATURE] This option allows you to select the color temperature of your choice.
5. Using On-Screen Menu [RESET] The settings and adjustments for [CONTRAST], [BRIGHTNESS], [SHARPNESS], [COLOR], [HUE], and [REFERENCE] within [PRESET] will be returned to the factory settings. The settings and adjustments under [DETAIL SETTINGS] within the [PRESET] screen that are not currently selected will not be reset.
5. Using On-Screen Menu [IMAGE OPTIONS] Adjusting Clock and Phase [CLOCK/PHASE] This allows you to manually adjust CLOCK and PHASE. CLOCK ������������������� Use this item to fine tune the computer image or to remove any vertical banding that might appear. This function adjusts the clock frequencies that eliminate the horizontal banding in the image. This adjustment may be necessary when you connect your computer for the first time.
5. Using On-Screen Menu Adjusting Horizontal/Vertical Position [HORIZONTAL/VERTICAL] Adjusts the image location horizontally and vertically. - An image can be distorted during the adjustment of [CLOCK] and [PHASE]. This is not malfunction. - Your manual adjustments for [CLOCK], [PHASE], [HORIZONTAL], and [VERTICAL] will be stored in memory for the current signal. The next time you project the signal with the same resolution, horizontal and vertical frequency, its adjustments will be called up and applied.
5. Using On-Screen Menu NATIVE The projector displays the current image in its true resolution when the incoming computer signal has a lower resolution than the projector’s native resolution. [Example 1] When the incoming signal with the resolution of 800 x 600 is displayed on the NP115/NP110: [Example 2] When the incoming signal with the resolution of 800 x 600 is displayed on the NP215/NP210: NOTE: • When a non-computer signal is displayed, the [NATIVE] is not available.
5. Using On-Screen Menu Turning on Noise Reduction [NOISE REDUCTION] This function allows you to select the level of noise reduction. The projector is set to the optimized level for each signal at the factory. Select your preference item for your signal when video noise is noticeable. The options are [OFF], [LOW], [MEDIUM], and [HIGH]. NOTE: This feature is not available for the RGB signal. Noise reduction set to off gives best image quality by way of higher bandwidth.
5. Using On-Screen Menu 6 Menu Descriptions & Functions [SETUP] [GENERAL] Correcting Vertical Keystone Distortion Manually [KEYSTONE] You can correct vertical distortion manually. (→ page 23) TIP: When this option is highlighted, pressing the ENTER button will display its slide bar for adjustment. Saving Vertical Keystone Correction [KEYSTONE SAVE] This option enables you to save your current keystone settings. OFF ������������������������ Does not save current keystone correction settings.
5. Using On-Screen Menu Setting Eco Mode [ECO MODE] This feature turns on or off the ECO mode. The lamp life can be extended by selecting [ON]. Selecting [ON] also decreases fan noise when compared to [OFF] mode. ECO MODE Description Status of LAMP indicator OFF This is the Default setting (100% Brightness). Off ON Select this mode to increase the lamp life Steady Green light (approx. 90% Brightness.) NOTE: • The [LAMP LIFE REMAINING] and [LAMP HOURS USED] can be checked in [USAGE TIME].
5. Using On-Screen Menu [MENU] Selecting Menu Color [COLOR SELECT] You can choose between two options for menu color: COLOR and MONOCHROME. Turning On / Off Source Display [SOURCE DISPLAY] This option turns on or off input name display such as COMPUTER, VIDEO, S-VIDEO and No Input to be displayed on the top right of the screen. Turning ON/OFF Control ID [ID DISPLAY] ID DISPLAY ����������� This option turns on or off the ID number which is displayed when the ID SET button on the remote control is pressed.
5. Using On-Screen Menu Selecting Menu Display Time [DISPLAY TIME] This option allows you to select how long the projector waits after the last touch of a button to turn off the menu. The preset choices are [MANUAL], [AUTO 5 SEC], [AUTO 15 SEC], and [AUTO 45 SEC]. The [AUTO 45 SEC] is the factory preset. Selecting a Color or Logo for Background [BACKGROUND] Use this feature to display a blue/black screen or logo when no signal is available. The default background is [LOGO]. TIP: The logo can be changed.
5. Using On-Screen Menu [INSTALLATION] Selecting Projector Orientation [ORIENTATION] This reorients your image for your type of projection. The options are: desktop front projection, ceiling rear projection, desktop rear projection, and ceiling front projection. DESKTOP FRONT CEILING REAR DESKTOP REAR CEILING FRONT Disabling the Cabinet Buttons [CONTROL PANEL LOCK] This option turns on or off the CONTROL PANEL LOCK function. NOTE: • This CONTROL PANEL LOCK does not affect the remote control functions.
5. Using On-Screen Menu Selecting Communication Speed [COMMUNICATION SPEED] This feature sets the baud rate of the PC Control port (D-Sub 9P). It supports data rates from 4800 to 38400 bps. The default is 38400 bps. Select the appropriate baud rate for your equipment to be connected (depending on the equipment, a lower baud rate may be recommended for long cable runs). NOTE: Your selected communication speed will not be affected even when [RESET] is done from the menu.
5. Using On-Screen Menu [OPTIONS(1)] Selecting Fan Mode [FAN MODE] This option allows you to select three modes for fan speed: Auto mode, High speed mode, and High Altitude mode. AUTO ��������������������� The built-in fans automatically run at a variable speed according to the internal temperature. HIGH ���������������������� The built-in fans run at high speed. HIGH ALTITUDE ����� The built-in fans run at a high speed.
5. Using On-Screen Menu Enabling Key Sound and Error Sound [BEEP] This feature turns on or off the button sound or alarm when the following operations are performed.
5. Using On-Screen Menu [OPTIONS(2)] Using Off Timer [OFF TIMER] 1. Select your desired time between 30 minutes and 16 hours: OFF, 0:30, 1:00, 2:00, 4:00, 8:00, 12:00, 16:00. 2. Press the ENTER button on the remote control. 3. The remaining time starts counting down. 4. The projector will turn off after the countdown is complete. NOTE: • To cancel the preset time, set [OFF] for the preset time or turn off the power.
5. Using On-Screen Menu Turning On the Projector By Applying Computer Signal [AUTO POWER ON(COMP.)] When the projector is in Standby mode, applying a computer signal from a computer connected to the COMPUTER IN input will power on the projector and simultaneously project the computer’s image. This functionality eliminates the need to always use the POWER button on the remote control or the projector cabinet to power on the projector.
5. Using On-Screen Menu 7 Menu Descriptions & Functions [INFO.] Displays the status of the current signal and lamp usage. This item has three pages (four pages on NP215). The information included is as follows: TIP: Pressing the HELP button on the remote control will show the [INFO.] menu items. [USAGE TIME] [LAMP LIFE REMAINING] (%)* [LAMP HOURS USED] (H) [TOTAL CARBON SAVINGS] (kg-CO2) * The progress indicator shows the percentage of remaining bulb life.
5.
5. Using On-Screen Menu 8 Menu Descriptions & Functions [RESET] [NP210/NP115/NP110] [NP215] Returning to Factory Default [RESET] The RESET feature allows you to change adjustments and settings to the factory preset for a (all) source (s) except the following: [CURRENT SIGNAL] Resets the adjustments for the current signal to the factory preset levels.
6. Maintenance This section describes the simple maintenance procedures you should follow to clean the cabinet and the lens, and replace the lamp. Cleaning the Cabinet and the Lens 1. Turn off the projector before cleaning. 2. Clean the cabinet periodically with a damp cloth. If heavily soiled, use a mild detergent. Never use strong detergents or solvents such as alcohol or thinner. Vacuum the ventilation inlet of the cabinet.
6. Maintenance Replacing the Lamp When the lamp reaches the end of its life, the LAMP indicator in the cabinet will blink red. Even though the lamp may still be working, replace the lamp to maintain the optimal projector performance. After replacing the lamp, be sure to clear the lamp hour meter. (→ page 63) CAUTION • DO NOT TOUCH THE LAMP immediately after it has been used. It will be extremely hot. Turn the projector off, and then disconnect the power cable.
6. Maintenance 1. Remove the lamp cover. (1) Loosen the lamp cover screw • The lamp cover screw is not removable. (2) Push and slide the lamp cover off. 2. Remove the lamp housing. (1) Loosen the three screws securing the lamp housing until the phillips screwdriver goes into a freewheeling condition. • The three screws are not removable. • There is an interlock on this case to prevent the risk of electrical shock. Do not attempt to circumvent this interlock. (2) Remove the lamp housing by holding it.
6. Maintenance 3. Install a new lamp housing. (1) Insert a new lamp housing until the lamp housing is plugged into the socket. CAUTION Do not use a lamp other than the NEC replacement lamp NP13LP. Order this from your NEC dealer. (2) Push the top center of the lamp housing to secure it. (3) Secure it in place with the three screws. • Be sure to tighten the screws. Hold the cabinet with your hand to keep it from tilting while you tighten the screw. 4. Reattach the lamp cover.
7. Appendix Troubleshooting This section helps you resolve problems you may encounter while setting up or using the projector. Indicator Messages Power Indicator Indicator Condition Off Blinking light Steady light Projector Condition Note The power cable is unplugged. – 0.5 sec On, 0.5 sec Off The projector is getting ready to turn on. Wait for a moment. 2.5 sec On, 0.5 sec Off Off Timer is enabled. – Green The projector is turned on.
7. Appendix Common Problems & Solutions (→ “Power/Status/Lamp Indicator” on page 68.) Problem Check These Items Does not turn on or shut down • Check that the power cable is plugged in and that the power button on the projector cabinet or the remote control is on. (→ pages 16 and 17) • Ensure that the lamp cover is installed correctly. (→ page 67) • Check to see if the projector has overheated.
7. Appendix If there is no picture, or the picture is not displayed correctly. • Power on process for the projector and the PC. Be sure to connect the projector and notebook PC while the projector is in standby mode and before turning on the power to the notebook PC. In most cases the output signal from the notebook PC is not turned on unless connected to the projector before being powered up. NOTE: You can check the horizontal frequency of the current signal in the projector’s menu under Information.
7. Appendix Specifications This section provides technical information about the NP215/NP210/NP115/NP110 projector's performance. Model Number NP215/NP210/NP115/NP110 Optical Projection System 1 Resolution* Lens Lamp Light Output*2,*3 Contrast Ratio*3 (full white: full black) Image Size (Diagonal) Projection Distance Projection Angle *1 2 * *3 Single DLP™ chip (0.55", aspect 4:3) NP215/NP210: 1024 x 768 pixels NP115/NP110: 800 x 600 pixels Manual zoom and focus F=2.41-2.55, f=21.8-24.
7. Appendix Mechanical Installation Dimensions Net Weight Environmental Considerations Orientation: Desktop/Front, Desktop/Rear, Ceiling/Front, Ceiling/Rear 12.2"(W) x 3.7 (H) x 9.7"(D) 310 mm (W) x 95 mm (H) x 247 mm (D) (not including protrusions) 5.5 lbs / 2.
7. Appendix Cabinet Dimensions NP215 247(9.7) NP210/NP115/NP110 310(12.2) 96(3.8) 95 (3.7) Lens center 68.4 (2.
7. Appendix Pin Assignments of D-Sub COMPUTER Input Connector Mini D-Sub 15 Pin Connector 6 11 12 13 14 15 7 8 9 10 1 2 3 4 5 Signal Level Video signal : 0.7Vp-p (Analog) Sync signal : TTL level Pin No.
7.
7.
7. Appendix Troubleshooting Check List Before contacting your dealer or service personnel, check the following list to be sure repairs are needed also by referring to the “Troubleshooting” section in your user’s manual. This checklist below will help us solve your problem more efficiently. * Print this page and the next page for your check.
7. Appendix In the space below please describe your problem in detail. Information on application and environment where your projector is used Projector Installation environment Model number: Screen size: Serial No.
7. Appendix TravelCare Guide 6) Problems or damage caused by expendable supplies or devices connected to the product other than those designated by NEC. TravelCare - a service for international travelers 7) Problems caused by natural consumption, wear or deterioration of parts under normal usage conditions. This product is eligible for “TravelCare”, NEC’s unique international warranty. Please note that TravelCare coverage differs in part from coverage under the warranty included with the product.
7. Appendix In Asia and Middle East NEC Display Solutions, Ltd. Address: 686-1, Nishioi, Oi-Machi, Ashigarakami-Gun, Kanagawa 258-0017, Japan Telephone: +81 465 85 2369 Fax Line: +81 465 85 2393 Email Address: support_pjweb@gw.necds.nec.co.jp WEB Address: http://www.nec-pj.com Hyosung ITX Co., Ltd. Address: 1st Fl., Ire B/D. #2, 4Ga, Yangpyeng-Dong, Youngdeungpo-Gu, Seoul, Korea 150-967 Telephone: +82 2 2163 4193 Fax Line: +82 2 2163 4196 Email Address: moneybear@hyosung.
7. Appendix Date: / / P-1/ , , TO: NEC or NEC’s Authorized Service Station: FM: (Company & Name with signature) Dear Sir (s), I would like to apply your TravelCare Service Program based on attached registration and qualification sheet and agree with your following conditions, and also the Service fee will be charged to my credit card account, if I don’t return the Loan units within the specified period. I also confirm following information is correct. Regards.
7. Appendix Condition of your TravelCare Service Program 5. Loan Service Charges and Conditions: Upon acceptance of this NEC Projector, Customer agrees to assume liability for this loan unit. Enduser is requested to understand following condition of TravelCare Service Program and complete the necessary information on the application sheet. The current cost of use of this loan unit is US$200 for 12 calendar days.
