CONFIGURATION GUIDE – NEC EXPRESS5800/R120b-2
NEC Corporation Revision 5.2, September 2011 41
Revision History
Revision
Date
Description
5.2
September 15, 2011
Others:
Correct incorrect part numbers for 50 GB SSD, PS/2 Switch Unit Connection
Cable Set.
Correct incorrect information in Specification, 10.1 17-inch LCD Console
Drawer, OS Support Matrix for PCI Cards, and Supporting PCI Cards and
Installable Slots.
5.1
August 24, 2011
Others:
Add section for Medium and Cartridge
5.0
July 29, 2011
New products added:
300GB 15K 2.5-inch SAS HDD / N8150-331
900GB 10K 2.5-inch SAS HDD / N8150-332
Discontinued products removed:
SCSI Controller / N8103-75
100BASE-TX Adapter / N8104-111
4.0
June 6, 2011
New product added:
Internal DVD Super Multi Drive / N8151-104F
3.0
April 8, 2011
New products added:
1TB 7.2K 2.5-inch SATA HDD / N8150-334
2.0
February 16, 2011
Others:
50GB SSD been re-added
1.0
February 14, 2011
Initial release
