CONFIGURATION GUIDE – NEC EXPRESS5800/R120b-2
NEC Corporation Revision 5.2, September 2011 34
10.6 Medium and Cartridge
Category
Product Name
Drive supported
Part Number
RDX
RDX Cartridge (160GB)
N8151-86
N8152-20
RDX Cartridge (320GB)
N8151-86
N8152-26
RDX Cartridge (500GB)
N8151-86
N8152-27
RDX Cartridge (640GB)
N8151-86
N8152-30
RDX Cartridge (1TB)
N8151-86
N8152-33
11 Support Service
11.1 Software
Product Name / Description
Part Number
PP Support Pack (VMware ESXi 4.1 for 1 processor)(1year)
Technical Support Service regarding ESXi (for quick solutions to technical issues)
NOTE: It is necessary to purchase a PP support pack for each processor installed in the
system.
ULH1S-SV40-008F
