CONFIGURATION GUIDE – NEC EXPRESS5800/R120b-2
NEC Corporation Revision 5.2, September 2011 32
9.2 Redundant Fan
Product Name / Description
Part Number
Redundant Fan
Hot plug redundant cooling fan for R120b-2
N8181-65
9.3 VMware ESXi Pre-install Kit
Product Name / Description
Part Number
VMware ESXi 4.1 Base Kit
Including USB flash memory, VMware ESXi 4.1 Recovery CD
NOTE:
The Base Kit may not be available in some regions. Please contact our sales
representative to confirm if it is available in your country.
The Base Kit must be ordered with the base model.
Installation of VMware ESXi onto hard drives is not supported.
N8106-004F
10 Add-on Components
10.1 17-inch LCD Console Drawer
Category
Product Name / Description
Part Number
Drawer
w/ KVM
Drawer
17inch LCD Console Unit (1U/8port)
17-inch LCD, US 83-keys Keyboard, Optical mouse, 8 port KVM
switch, 1U height
N8143-69F
Cable
Switch Unit Connection Cable Set (USB, 1.8m)
1.8 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin
USB A
K410-118(1A)
Switch Unit Connection Cable Set (USB, 3m)
3 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin
USB A
K410-118(03)
Switch Unit Connection Cable Set (USB, 5m)
5 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin
USB A
K410-118(05)
Switch Unit Connection Cable Set (PS/2, 1.8m)
1.8 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 2 x 6-pin
mini DIN
K410-119(1A)
Switch Unit Connection Cable Set (PS/2, 3m)
3 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 2 x 6-pin
mini DIN
K410-119(03)
Switch Unit Connection Cable Set (PS/2, 5m)
5 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 2 x 6-pin
mini DIN
K410-119(05)
Drawer
w/o KVM
Drawer
17inch LCD Console Unit 1U
17-inch LCD, US 83-keys Keyboard, Optical mouse, 1U height,
4-pin USB B to 4-pin USB A cable 2m, PS/2 Y-splitter cable 2m,
15-pin mini D-sub VGA cable 2m
N8143-76F
