CONFIGURATION GUIDE – NEC EXPRESS5800/R120b-2
NEC Corporation Revision 5.2, September 2011 31
8.3 External RAID Controller
Category
Product Name / Description
Part Number
Controller
RAID Controller (512MB, RAID0/1/5/6)
Promise SuperTrak EX8768
RAID 0/1/5/6, 512MB, Ext. 8, PCIe 2.0 x8, SAS 6Gb/s, SATA
3Gb/s, LP / FH
N8103-135
RAID BBU
RAID Battery Backup Unit
for Promise SuperTrak EX8760T and EX8768
N8103-140
8.4 Fibre Channel / SAS / SCSI Controller
Category
Product Name / Description
Part Number
Fibre Channel
Fibre Channel Controller (1ch)
Emulex LightPulse LPe1250-F8 Host Bus Adapter
8Gb/s, Optical, PCIe 2.0 x8, LP / FH
N8190-153
Fibre Channel Controller (2ch)
Emulex LightPulse LPe12002-M8 Host Bus Adapter
8Gb/s, Optical, PCIe 2.0 x8, LP / FH
N8190-154
Fibre Channel Controller (1ch)
Emulex LightPulse LPe1150-F4 Host Bus Adapter
4Gb/s, Optical, PCIe x4, LP / FH
N8190-127
Fibre Channel Controller (2ch)
Emulex LightPulse LPe11002-M4 Host Bus Adapter
4Gb/s, Optical, PCIe 2.0 x8, LP / FH
N8190-131
SCSI
SCSI Controller
Adaptec SCSI Card 29320LPE 1-channel
U320, 68-pin D-sub / 68-pin VHDC, PCIe x1, LP/FH
N8103-107
SAS
SAS Controller
LSI SAS3442E-R Host Bus Adapter
3Gb/s SAS, Int. 4 / Ext. 4, SFF-8484 / SFF8470, PCIe x8, LP/FH
N8103-104A
SAS Controller
LSI SAS9212-4i4 Host Bus Adapter
6Gb/s SAS, Int. 4 / Ext. 4, 7-pin SATA / SFF-8088, PCIe 2.0 x8,
LP/FH
N8103-142
8.5 Serial Port Adapter
Product Name / Description
Part Number
Serial Port Adapter
Serial port fixed to PCI bracket
N8117-01A
9 Other Add-in Components
9.1 Redundant Power Supply
Product Name / Description
Part Number
Power Unit
1 x 750 Watt 80 PLUS® Gold certified Hot plug Power Supply
N8181-77F
