CONFIGURATION GUIDE – NEC EXPRESS5800/R120b-2
NEC Corporation Revision 5.2, September 2011 28
5 Optical Drive
Category
Product Name / Description
Part Number
Internal
1 slot available
Internal Slim DVD-ROM drive
Slim DVD-ROM drive
N8151-100
Internal DVD Super Multi Drive
Slim DVD Super Multi drive, not including writing software
N8151-104F
External
External DVD-ROM drive
Slim DVD-ROM drive, Bus powered, 0.8 A required
N8160-85
NOTE:
Up to 1 optical drive can be connected.
6 Floppy Drive / Flash FDD
Category
Product Name / Description
Part Number
Internal
1 slot
available
Drive
Internal USB FDD
2 mode
N8151-92
Cable
Internal USB Cable
1 x USB-FDD cable
K410-193(00)
External
Flash FDD
USB flash emulating USB floppy disk, Native capacity 1.44 MB
N8160-86
NOTE:
Up to 1 drive can be connected.
7 Internal Tape / RDX Drives
7.1 Tape / RDX Drive Selection
Refer to the section in accordance with your type of tape drives.
NOTE:
Tape devices cannot be directly connected to VMware systems. For VMware systems, it is
recommended to connect and configure an additional backup server via network.
DAT
DAT72
USB
Refer to 7.2.1
DAT160
USB
SCSI
Refer to 7.2.2
Refer to 7.2.1
Refer to 7.2.3
USB
RDX
