CONFIGURATION GUIDE – NEC EXPRESS5800/R120b-2
NEC Corporation Revision 5.2, September 2011 26
4.2.8 3.5-inch Drives with On-board SATA Controller
Category
Product Name / Description
Part Number
Storage Controller
On-board SATA Controller
4 x SATA ports
(Standard)
Cable
Internal SAS/SATA Cable
1 x mini-SAS to 1 x mini-SAS
(Standard)
HDD Cage
3.5-inch HDD Cage
6 x 3.5-inch hot plug hard drive bays
(Standard)
HDD
4 slots available
250GB HDD
1 x 250 GB, 3.5-inch, SATA2, 7,200 rpm
N8150-209A
500GB HDD
1 x 500 GB, 3.5-inch, SATA2, 7,200 rpm
N8150-274
1TB HDD
1 x 1 TB, 3.5-inch, SATA2, 7,200 rpm
N8150-263
2TB HDD
1 x 2 TB, 3.5-inch, SATA2, 7,200 rpm
N8150-278
NOTE:
Up to four hard drives can be installed in the configuration.
Hot plug insertion/removal are not supported in the configuration.
4.2.9 3.5-inch Drives with RAID 0/1 Controller with 256 MB Cache
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (256MB, RAID 0/1)
LSI MegaRAID SAS 9264-8i
RAID 0/1, 256MB, Int. 8, PCIe 2.0 x8, SAS 6Gb/s, SATA 3Gb/s,
LP / FH
N8103-129
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9264
N8103-123
Cable
Internal SAS/SATA Cable
1 x mini-SAS to 1 x mini-SAS, 2 sets
(Standard)
HDD Cage
3.5-inch HDD Cage
6 x 3.5-inch hot plug hard drive bays
(Standard)
HDD
6 slots available
250GB HDD
1 x 250 GB, 3.5-inch, SATA2, 7,200 rpm
N8150-209A
500GB HDD
1 x 500 GB, 3.5-inch, SATA2, 7,200 rpm
N8150-274
1TB HDD
1 x 1 TB, 3.5-inch, SATA2, 7,200 rpm
N8150-263
2TB HDD
1 x 2 TB, 3.5-inch, SATA2, 7,200 rpm
N8150-278
NOTE:
All hard drives within a RAID array should be of the same capacity and rotation speed.
