CONFIGURATION GUIDE – NEC EXPRESS5800/R120b-2
NEC Corporation Revision 5.2, September 2011 17
Maximum Available Memory
See the table below for the maximum memory size that you can actually use on your system.
The maximum available memory is less than the maximum physical memory supported by your system
because some chipsets require PCI resource space of about 750MB. PCI resource requirements vary
depending on the type and the number of PCI cards you are using.
Maximum Memory Size Supported by OS
Maximum Available Memory
4 GB
Microsoft Windows Server 2003, Standard Edition(SP1)
Microsoft Windows Server 2003 R2, Standard Edition
Microsoft Windows Server 2008 Standard
4 GB (HW-DEP enabled)
App. 3.6 GB (HW-DEP disabled)
32 GB
Microsoft Windows Server 2003 R2, Standard x64 Edition
Microsoft Windows Server 2008 Standard (x64)
Microsoft Windows Server 2008 R2 Standard (x64)
32 GB
64 GB
Microsoft Windows Server 2003, Enterprise Edition(SP1)
Microsoft Windows Server 2003 R2, Enterprise Edition
Microsoft Windows Server 2008 Enterprise
64 GB
1 TB
Microsoft Windows Server 2003 R2, Enterprise x64 Edition
192 GB
2 TB
Microsoft Windows Server 2008 Enterprise (x64)
Microsoft Windows Server 2008 R2 Enterprise (x64)
192 GB
16 GB
Red Hat Enterprise Linux ES4
Red Hat Enterprise Linux ES4 (EM64T)
Red Hat Enterprise Linux 5
Red Hat Enterprise Linux 5 Advanced Platform
Red Hat Enterprise Linux 6
SUSE Linux Enterprise Server 10
SUSE Linux Enterprise Server 11
16 GB
64 GB
Red Hat Enterprise Linux AS4
64 GB
256 GB
Red Hat Enterprise Linux AS4 (EM64T)
Red Hat Enterprise Linux 5 (EM64T)
Red Hat Enterprise Linux 5 Advanced Platform (EM64T)
192 GB
2 TB
Red Hat Enterprise Linux 6.0 (x86_64)
192 GB
512 GB
SUSE Linux Enterprise Server 10 (EM64T)
SUSE Linux Enterprise Server 11 (EM64T)
192 GB
256 GB
or 1TB
1
VMware ESXi 4.1
192 GB
1
Up to 255 GB of main memory is available to each virtual machine.
