6. Setting Up Windows Server 2003
Express5800/GT-110e, GT-110e-S, R110e-1E Installation Guide (Windows)
211
Chapter 1 Installing Windows
When the following message appears, set OS installation media, and click [OK].
18. The server automatically restarts.
To use OEM driver, change boot priority of Flash FDD on BIOS settings, after restarting the server.
Select Boot, Floppy Drive BBS priorities, Boot Option #1, and then specify the Flash FDD used.
19. Run from the OS installation media.
If a bootable operating system is already installed on the hard disk drive, press <Enter> key while the
message "Press any key to boot from CD or DVD…" is displayed on the top of the screen.
The boot sequence proceeds and the following message appears.
Note
If this message does not appear, reboot the server and retry.
This step is unnecessary if no bootable operating system exists.
20. If a RAID controller or an optional mass storage controller is used, press <F6> key while either of the
following messages is displayed. If not, go to step25 without pressing <F6> key.
"Setup is inspecting your computer's hardware configuration" (on the top of the screen)
"Press F6 if you need to install a third party SCSI or RAID driver…" (on the bottom of the screen)
Tips
• Note that nothing changes on the screen even when the <F6> key is pressed.
• If the OEM drivers list is not displayed at step 22, 24, check the boot order of the
Flash FDD on BIOS settings.
