5. Setting Up Windows Server 2003 R2 x64 Edition
Express5800/GT-110e, GT-110e-S, R110e-1E Installation Guide (Windows)
166
Chapter 1 Installing Windows
25. When the following message appears, press <Enter> key to start Windows setup.
The following screen is displayed for setting the partition of Windows.
If the partition created is shown as "G:", delete the partition "G:"
Important
Pay attention to a partition you are going to delete.
If it is shown as "C:", you do not need to delete the partition and go to step 26.
Create a partition again by pressing <C> key.
The creation of partition completes when the new partition is created in drive "C:", as shown below.
Important
• A partition in which you install Windows must be created in drive "C:".
• When installing Windows Server 2003 R2 Edition to a disk of over 2,097,152
MB (2 TB), the partition size can only be set to 2,097,152 MB or less.
Tips
The server automatically restarts after copying files.
Do not remove the CD-ROM and the Flash FDD.
26. Follow the onscreen instructions to continue setup.
For details, refer to "First Step Guide" supplied with the OS.
Tips
When a driver is selected from the drive list, the message indicating that the driver
has not passed logo testing might appear, but this does not affect the setup. Click
[OK] to continue setup.
27. The server automatically restarts after installing Windows Server 2003 R2 x64 Edition.
