Swing Gate Series Networking Cabinet
NavePoint Swing Gate Series of cabinets is designed to house EIA standard
19 inch equipment in oces, network closets, retail locations and classrooms.
This series is the best solution for IT professionals who require a secure
solution and have a need to have frequent access to their equipment.
Available in 6U and 9U these cabinets come pre-assembled and feature door
and side panel locks and a replaceable cable management cover.
Physical
Available Height
Options
(in Rack Units)
6U 9U 6U 9U
Available Depth
Options
600mm 600mm 450mm 450mm
Unit Dimensions
(HxWxD/in.)
14.75x23.75x23.75 20x23.75x23.75 14.63x23.63x21.63 19.88x23.63x21.63
Maximum Rail
Depth (in.)
18.5 18.5 16 16
Shipping Weight
(lbs)
50.05 59.45 50.7 58.7
Shipping
Dimensions
(LxWxH/in.)
24.75x24.5x15.5 20.5x24.5x24.5 27x24.75x19 27.25x25.5x24
Weight Capacity
(lbs)
130 130 132 132
Paint
Black Powder Coated Black Powder Coated Black Powder Coated Black Powder Coated
Material
Cold Rolled Steel
(1.2mm) Welded
Frame Structure
Cold Rolled Steel
(1.2mm) Welded
Frame Structure
Cold Rolled Steel
(1.2mm) Welded Frame
Structure
Cold Rolled Steel
(1.2mm) Welded Frame
Structure
Door Type
Tempered Glass Door
- Clear/Reversible
Tempered Glass Door
- Clear/Reversible
Perforated Door Perforated Door
Interior Rails
Mounting
Square unthreaded
cage nut opening
Square unthreaded
cage nut opening
Square unthreaded
cage nut opening
Square unthreaded
cage nut opening
Model/SKU 00404141 00404142 00406038 0040639
Solid Panel/Glass Door Cabinets Perforated Panel/Door Cabinets
