Main Page
The Limiter in the Control area: Main page.
Parameter Description
DEPTH Section
Threshold This value determines the threshold where the Limiter kicks in. If you use it to
prevent your signal from clipping, leave it at 0 dB; if you want to make your
signal louder, dial the Knob to the left.
The Limiter on the controller: MAIN page.
Side-Chain Input Page
The Limiter in the Control area: Side-Chain Input page.
Effect Reference
Dynamics
MASCHINE STUDIO - Manual - 537
