The Audio page of the Input properties for a Sound in the software.
The AUDIO page of the Input properties for a Sound on the controller.
Please refer to section ↑2.3.3, Navigating Channel Properties, Plug-ins, and Parameter Pa-
ges in the Control Area to know how to access the Audio page of the Input properties in the
software and from your controller.
Controls Description
AUDIO Section
Source Select an external audio input to be routed to the Sound. Available entries are
None (no external input) and the four external stereo inputs Ext. 1–4, as well
as any additional output(s) of multiple-output Plug-ins loaded in other Sounds
of the same Group. Check the Routing page of the Audio and MIDI Settings
panel to route the physical inputs of your audio interface to the virtual audio
inputs of MASCHINE (see section ↑2.6.1, Audio and MIDI Settings – Audio
Page).
Gain Adjust the gain of the incoming signal.
Audio Routing, Remote Control, and Macro Controls
Audio Routing in MASCHINE
MASCHINE STUDIO - Manual - 352
