The Event Edit mode on the controller with pads in Keyboard mode.

▪ The left display shows an overview of the events in your Pattern for all pitches of the fo-

cused Sound.

▪ The right display shows a detailed view of a portion of your Pattern containing events on

two octaves.

You can adjust the right display as follows:

►

Turn Knob 5 and 6 to zoom in/out and scroll on the time axis (horizontal axis), respec-

tively.

►

If your pads are in Keyboard mode, turn Knob 7 to scroll on the pitch axis (vertical axis)

from events at the lowest pitch until events at the highest pitch.

The Event Edit mode is well suited for use with the Event Select mode! For example, while

in Event Edit mode, you can quickly hold EVENTS (in the TRANSPORT section of your con-

troller) to momentarily switch to Event Select mode, select particular events, and release

EVENTS to switch back to Event Edit mode and edit the events you have just selected!

The Event Edit mode additionally provides a few selection shortcuts inspired from Event

Select mode: Hold SHIFT and use Button 5 and 6 to select/deselect all events displayed,

and Button 7 and 8 to switch the focus to the previous/next Sound in the Group, respec-

tively.

Under the left display Knob 1–4 provide following editing functions:

Working with Patterns

Editing Events

MASCHINE STUDIO - Manual - 297
