2. Select Single Mode from the menu in TRAKTOR's effect units 1 and 2, and a different
effect for each.
3. Press the left-hand FX Assign button.The button will be backlit orange.
4. Ensure that all of the FX knobs have their marker set to the 12 o'clock position.
5. Press the top FX (Mode) button, located at the top left of the X1. The button will now be
backlit orange, and you will be able to hear that the track playing is now affected by
TRAKTOR's corresponding effect.
6. Turn the top FX (Dry/Wet) knob to the left. You will hear the amount of the assigned effect
lessens.
7. Turn the FX (Dry/Wet) knob all the way towards the right. You will hear that the track play-
ing is now affected with more of the assigned effect. The further right the FX knob is
turned, the more the applied effect affects the sound of the track.
8. To turn this effect off, you can either press the top FX (Mode) button again, or press the
FX Assign button again. In this case, press the FX Assign button again.
9. Now assign Deck A to TRAKTOR's effect unit 2 by pressing the right-hand FX Assign but-
ton. The FX Assign button is now backlit orange.
10. Press the top FX (Mode) button (located at the top right hand corner) on the X1. The but-
ton will be backlit orange, and you will now be able to hear the track being affected with
TRAKTOR effect unit 2's effect.
11. Like previously, turn the corresponding FX knob to either side to hear how the Dry/Wet pa-
rameter of the effect can be controlled.
By pressing both of TRAKTOR's FX Assign buttons; you can utilize two of TRAKTOR's ef-
fects units at once on a single Deck.
Selecting Group Mode in TRAKTOR's effect units allows for a greater range of effects potential
and control using the X1.
You can switch a TRAKTOR effect unit from Single Mode to Group mode in the following way:
►
Hold SHIFT + press the X1's corresponding FX (MODE) buttons to switch the TRAKTOR
effect unit into Group mode.
The X1 controls a TRAKTOR effect unit in Group mode in the following way:
Key functions when using the X1 with TRAKTOR
Effects Section
