Chapter 2 Configuration and Installation

SCXI-1121 User Manual 2-8 www.natinst.com

Input Channel Jumpers

Gain Jumpers

Each input channel has two gain stages. The first gain stage provides gains

of 1, 10, 50, and 100 and the second stage provides gains of 1, 2, 5, 10, and

20. Tables 2-3 and 2-4 show how to set up the gain for each channel.

The board is shipped to you with the first-stage gain set to 100 (position A)

and a second-stage gain set to 10 (position D). To change the gain of your

module, move the appropriate jumper on your module to the position

indicated in Table 2-4. Refer to Figure 2-2 for the jumper locations on your

module.

To determine the overall gain of a given channel use the following formula:

Overall gain = First-stage gain × second-stage gain

Table 2-3.

Gain Jumper Allocation

Input Channel

Number

First Gain

Jumper

Second Gain

Jumper

0 W3 W4

1 W19 W20

2 W29 W30

3 W41 W42

Table 2-4.

Gain Jumper Positions

Gain Setting Jumper Position

First-stage 1

100

A (factory setting)

Second-stage 1

D (factory setting)
