Appendix D SCXI-1121 Front Connector
© National Instruments Corporation D-3 SCXI-1121 User Manual
Front Connector Signal Descriptions
Pin
Signal
Name
Description
A2 CGND Chassis Ground—This pin is tied to the SCXI chassis.
C2 DTEMP Direct Temperature Sensor—This pin connects the temperature
sensor to the MCH4+ when the terminal block is configured for
direct temperature connection.
A4 +5 V +5 VDC Source—This pin is used to power the temperature sensor
on the terminal block. 0.2 mA of source not protected.
C4 MTEMP Multiplexed Temperature Sensor—This pin connects the
temperature sensor to the output multiplexer.
A6 SCAL Shunt Calibration—This pin is tied to the SCAL bit and is used to
control the SCXI-1321 shunt calibration switch. CMOS/TTL
output; not protected.
C6, C8 RSVD Reserved—These pins are reserved. Do not connect any signal to
these pins.
A8, C10, C16,
C22, C28
No Connect Do not connect any signal to these pins.
A10 EGND3 Excitation Ground 3—This pin connects to the excitation ground 3
via a 51 kΩ resistor.
A12 EX3+ Positive Excitation Output 3—This pin is connected to the
excitation channel 3 positive output.
C12 EX3– Negative Excitation Output 3—This pin is connected to the
excitation channel 3 negative output.
A14 CH3+ Positive Input Channel 3—This pin is connected to the input
channel 3 positive input.
C14 CH3– Negative Input Channel 3—This pin is connected to the input
channel 3 negative input.
A16 EGND2 Excitation Ground 2—This pin connects to the excitation ground 2
via a 51 kΩ resistor.
A18 EX2+ Positive Excitation Output 2—This pin is connected to the
excitation channel 2 positive output.
